NovaStar - SFP module 10G multi mode - 10G SFP multi mode transceiver module for all Novastar products equipped with SFP fibre port

I moduli ricetrasmettitori SFP 10G possono essere utilizzati con tutti i prodotti Novastar dotati di porta in fibra SFP. Tali prodotti includono i modelli MCTRL 4K  / CVT4KS  / MCTRL 660PRO  / R5 / Pro HD / UHD jr. / UHD. Tutti i moduli SFP sono dotati di connettore LC e sono pertanto facili da abbinare ai cavi di break-out in fibra ottica e agli avvolgicavo. Connettore LC  Distanza di trasmissione fino a 10 km Supporta velocità di trasmissione in bit da 9,95 a 11,3 Gb/s Hot-pluggable - - - - - - - - - - The Novastar 10G SFP transceiver modules can be used for all Novastar products which are equipped with SFP fibre port. Such as MCTRL 4 K / CVT4 KS / MCTRL 660PRO / R5 / Pro HD / UHD jr. / UHD. All SFP modules are equipped with LC connector, and therefore easy to combine with the Highlite fibre optic breakout cables and drums. LC-connector Transfer up to 10 km Supports 9.95 to 11.3 Gb/s bit rates Hot-pluggable   - - - - - - - - - -

Optical

SFP Module Fibre Connector Type: LC
Fibre Mode: Multi-mode
Maximum Transmission Distance: 10000 m

Control and Programming

Control System: Novastar
Port Mapping: Software Based

Electrical Specifications and Connections

Power supply: 3 V_DC
Power Consumption: 1.5 W

Mechanical Specifications

Width (without handles): 14 mm
Height (without handles): 12 mm
Depth (without handles): 57 mm
Weight: 0.02 kg
IP Rating: IP20 (indoor use only)

Thermal Specifications

Maximum Ambient Temperature: 70 °C
Operating Humidity: 0-80 %RH
