Descrizione
» Specifiche tecniche / Technical specs | » English description
Descrizione (IT): Switcher di produzione live ad alta definizione ricco di funzioni avanzate. Il design con un banco effetti M/E include 10 ingressi 3G-SDI con conversione di standard e 6 uscite aux 3G-SDI indipendenti. Inoltre offre un’uscita webcam USB DVE chiavi cromatiche media player multiview e molto altro.
- Peso: 2200 g
- Dimensioni (cm): 9 (H) × 33 (W) × 21 (L)
Description (EN)
ATEM 1 M/E Constellation HD is a high definition live production switcher packed with advanced features! The single M/E design includes 10 standards converted 3G‑SDI inputs and 6 independent 3G‑SDI aux outputs! It also includes a USB webcam output DVE chroma keyers media players multiview and more!
Specifiche Tecniche
- Total Video Inputs: 10
- Total Video Outputs: 6
- SDI Rates: 1.5G 3G
- Total Audio Inputs: 2 x balanced 1/4 inch Jack 1 x 5-pin XLR Talkback.
- Total Audio Outputs: 1 x 5-pin XLR Talkback.
- SDI Audio Inputs: 2 Ch embedded audio on all SDI inputs.
- SDI Audio Outputs: 2 Ch embedded audio on all SDI outputs.
- Time Code Connections: None
- Reference Input: Tri-Sync or Black Burst.
- Video Input Re-Sync: On all 10 inputs.
- Frame Rate and Format Converters: On all 10 inputs.
- SDI Aux Outputs: Any of the 6 SDI outputs.
- SDI Preview Outputs: Any of the 6 SDI outputs.
- SDI Program Outputs: Any of the 6 SDI outputs.
- Down Converted SDI Program Output: None
- Webcam Output: 1 x USB-C supporting 720p or 1080p at PGM frame rate.
- Total Multi Views: 1 x 3G-SDI
- Control Panel Connection: Ethernet. Direct connection between panel and chassis or via network.
- Internal Time Code Generator: Yes
- Talkback: RJ45 for 3rd party talkback systems.
- Tally Output: Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included).
- Ethernet: Supports 10/100/1000 BASE-T.
- Computer Interface: 1 x USB-C supports USB 3.1 Gen 1 (5Gb/s)
